GENERATOR SIMULATION
Company
Code
CRE Techology
Manufacturer of solutions for control and protection of power sources.
CRE
Context
Design and production of a real-time simulation of a generator coupled to the electrical grid, enabling users to experience on their desktop a range of products dedicated to generator control.
Mission
  • Hardware design for an electronic card interface between a STM32 and the generator controller Gensys COMPACT
  • Firmware programmation in C, analogic signals generation, allowing the product to live (three-phase voltage and current, analogic sensors, logical inputs/outputs, Can J1939)
  • Software to configure the simulation in C++ Qt, which communicates with computer via Modbus TCP.
  • Desktop use for R&D, after sales service, and for commercial demonstration suitcase.
    • Code
    Technical environment
    Code
    C
    STM32
    Firmware
    Programming in C on STM32 microcontroller.
    Code
    CPP
    QT
    Software
    User interface in C++ on Qt.
    Code
    KICAD
    OSCILLO
    Hardware
    Study and design of a signal processing card.
    Code
    JIRA
    GIT
    Project management
    Monitoring via Jira and Git.
